| Brand Name : | Starvision |
| Model Number : | SV-LED-601 |
| Price : | Negotiate |
| Payment Terms : | L/C, T/T |
| Supply Ability : | 100 units per month |
| Delivery Time : | 5-8 weeks after receipt of your payment |
| Certification : | CE |
Waterproof IP65 6 Sheet Outdoor LED Totem 5000 Nits Digital Mupi
6 Sheet 5000cd/㎡ P3 Outdoor Full Color Led Screen Digital Mupi
Main Feature
Product Discription
| Description of product | 6 Sheet Aluminum Alloy P3 Full Color SMD Advertising LED Digital Mupi For Urban City |
| Product dimensions(overall) | 1370mm x 2370mm x 200mm |
| Visual size | 1130X 1690mm |
| Mechanical construction | Welded powder coated extruded aluminum alloy body |
| Galvanized zinc reinforcement plate and stand | |
| Waterproof level | IP65 |
| Pixel Pitch(mm) | 3mm |
| Pixel Configuration | 1R1G1B |
| Real Pixel Resolutions (Pixels/m2) | 111111 |
| LED encapsulation | SMD2020 |
| Module size L*H(mm) | 192 x 96mm |
| Module resolution(pixels) | 64*32=2048DOTS |
| Brand of LEDs | Nationstar |
| Brand of power | Meanwell |
| Physical cabinet resolution(pixels) | 128*96 |
| Module weight | 600G |
| Best viewing distance | 3m-7.5m |
| Viewing angle level | 120° |
| Vertical | 100° |
| Mean time between failures | ≧5000 hours |
| Control method | synchronous control |
| Graphics card | DVI graphics card |
| Drive mode | 1/16 scan |
| Maximum power | ≤42W |
| Refresh frequency | 1000-4000Hz |
| White balance brightness | 2000 cd/㎡ |
| Operating system | windows |
| Video signal | RF,S-Video,RGB,RGBHV,YUV,YC,COMPOSITION, etc |
| Control System | PCTV card (optional) + DVI graphics card + main control card + optical fiber transmission (optional) |
| Life span | 75000-100000 hours |
| Available options | Side A with led screen,side B with static or scrolling poster |
Customize Design Available
With our engineering and design team, we can working more closely with client to produce customize products, you don’t have to provide the whole drawing, you can just drop an idea, and we will do the rest.
Production Process
SMD Range
3mm to 10mm pitch screens with SMD technology. The SMD technology is the very latest in technologies. The three basic colours (red, green,blue) are grouped and controlled via the same unit. The SMD range screens can be fitted to our 4 sheet, 6 sheet, 12 sheet, 16 sheet, 32 sheet digital board whether single or double-sided according to format.
Reasons To Choose Our SMD Range
|
|
